首页 /产品展示 /H型磁芯
H型磁芯HCX

H型磁芯

  • 质量稳定：实行全过程质量监控，一丝不苟，检测！
  • 合理的价格：有效的内部成本控制，减少开支，为客户服务！
  • 快速交货：完善的生产线，充足的库存，缩短交货时间！
  • 电话：15955032233
  • 传真：0539-6015306
  • 邮箱：351856373@qq.com、sales@yfcore.com
介绍


型号毛重外形尺寸磁芯参数AL±25%(nH/N^2)净重（g）
ABCC1LeAeVePC40ZH5KZH7KZH10K
H10/6/51.2510.0±0.36.0±0.255.0±0.252.4824.19.7233.71160


1.0
H16/9.6/85.116.0±0.39.6±0.38.0±0.31.5438.525.196418504400570081004.9
H20/10/101220.0±0.410.0±0.310.0±0.30.90843.547.920883150


11.5
H20/12/6620.0±0.412.0±0.36.0±0.252.05648.123.411301400


5.9
H22/14/88.722.0±0.414.0±0.48.0±0.41.7454.731.4172016603980506081108.4
H22/14/101122.0±0.414.0±0.410.0±0.41.3954.739.32150200049506300900010.5
H22/14/1516.522.0±0.414.0±0.415.0±0.40.9354.758.832153100740094501350016.0
H25/15/1014.825.0±0.515.0±0.510.0±0.31.2360.248.929442450510076501020014.0
H25/15/121825.0±0.515.0±0.512.0±0.31.0360.258.535202820674085801150017.5
H28/12.5/1535.628.0±0.612.5±0.615.0±0.30.5257.1109.2624455001200017000/34.0
H29/19/1527.529.0±0.619.0±0.415.0±0.50.9973.273.95409290069808850/26.5
H31/19/132931.0±0.619.0±0.413.0±0.40.9975.576.35759290069808850/28.0
H31/19/153431.0±0.619.0±0.415.0±0.50.8675.588.266603350800010100/32.8
H35/22/226235.0±0.622.0±0.422.0±0.50.61886.4139.71207546008000//59.5
H36/23/1955.536.0±0.823.0±0.519.0±0.50.7489.6121.2108643900930011850/53.0
H38/19/114638.0±1.019.0±0.811.0±0.50.8382.7100.282933500838010600/44.0
H38/19/135538.0±1.019.0±0.813.0±0.50.70282.7117.8975040008900
/53.0
H38/19/229238.0±1.019.0±0.822.0±0.50.4182.6200.21653570001600021000/90.0
H40/22/2087.540.0±1.022.0±0.820.0±0.50.5391.9174.81607455001310016700/84.0
H40/20/2288.540.0±1.020.0±0.822.0±0.50.41587.22101832069501400020000/85.5
H45/26/1260.545.0±1.526.0±1.212.0±0.60.92103.8112.511675303072409200/58.5
H45/30/156445.0±1.530.0±1.215.0±0.61.05114.6109.312500275059008000/62.0
H47/27/137347.0±1.127.0±0.813.0±0.50.87110.5126.7140023300790010100/70.5
H47/27/158447.0±1.127.0±0.815.0±0.50.76110145160503800///81.0
H49/31.8/157949.0±1.231.8±0.915.0±0.40.97123126155263000///74.5
H49/31.8/1910149.0±1.231.8±0.919.0±0.40.76123160197303800///95.0
H50/25/2014050.0±1.225.0±0.520.0±0.40.456108.6237.9258506300


135.0
H50/30/2012050.0±1.230.0±0.620.0±0.40.62120.2194234004600


115.0
H51/31/137951.0±1.231.0±0.819.0±0.51.015123.7121.8150612800///76.0
H56/28/2825056.0±1.228.0±0.828.0±0.60.324122.7377462008800///240.0
H56/32/1814456.0±1.232.0±0.818.0±0.50.634131.320727200450012000//139.0
H63/38/2524563.0±1.738.0±1.125.0±0.50.49151.2308.44662255001260017700/236.0
H63/39/2523763.0±1.739.0±1.125.0±0.50.537153.92874415050001150016500/227.0
H70/44/3236070.0±1.544.0±1.032.0±0.50.428173.5404.1700006700

/347.0
H80/52/2028280.0±2.052.0±1.520.0±1.00.73201.2275553243900

/272.0
H85/55/1320685.0±2.055.0±1.513.0±1.01.11212.9190.9406642600

/199.0
H85/55/2033585.0±2.055.0±1.520.0±1.00.72212.9294.2626464000

/323.0
H100/50/10534100.0±3.050.0±2.510.0±1.50.91217.7239.4521173150

/270.0
H100/50/20309100.0±3.050.0±2.520.0±1.50.45216.9477.91036996400

/550.0
H100/60/15393100.0±2.560.0±2.015.0±0.50.825240291.2702003400

/360.0
H102/65/20495102.0±3.065.0±3.020.0±1.50.7253.1362.1916304100

/465.0
H118/80/351060118.0±3.080.0±3.035.0±1.50.46303.6653.91985416250

/982.0
H124/60/20925124.0±3.560.0±3.020.0±1.50.88265.4301.5800043250

/860.0
H124/60/401710124.0±3.560.0±3.040.0±2.00.22262.31207.231664613000

/1600.0
H125/80/12460125.0±3.080.0±2.412.0±0.51.18311263.7822152350

/410.0
H140/106/30980140.0±3.5106.0±2.530.0±0.50.76381.5501.41912702350

/946.0
